Blue Spot Tools Ironmongery 200mm Zinc Plated Necked Tower Bolt 78064

Blue Spot Tools Ironmongery 200mm Zinc Plated Necked Tower Bolt

MPN: 78064

Barcode: 5028734780642

Size: 200mm

Weight: 0.34kg

Overview:

This 200mm necked tower bolt from Blue Spot Tools is built from carbon steel with a zinc-plated finish that guards against corrosion. The cranked neck design bridges the gap between a door face and a recessed or offset frame, giving a secure bolt throw where a standard flat bolt won't align.

It suits permanent outdoor installations on wooden garden gates, fence panels, and shed doors. All necessary fittings are included in the pack, and the bolt carries a 5-year guarantee from Blue Spot Tools.

Key Features and Benefits

• Carbon Steel Body: The carbon steel construction holds up to regular outdoor use without deforming under load.
• Zinc Plated Finish: The zinc coating acts as a barrier against rust and corrosion when exposed to rain and moisture.
• Cranked Neck Design: The offset neck spans the gap between a door surface and a recessed frame, giving a proper bolt throw where a straight bolt falls short.
• Multi-Orientation Fitting: Can be mounted horizontally or vertically to suit different gate and door setups.
• Fittings Included: Everything needed for mounting is supplied in the pack - no additional hardware required.
• Outdoor Rated: Designed for permanent installation in exposed outdoor positions on gates, outbuildings, and fencing.

Specs & Attributes

• Material: Carbon steel
• Finish: Zinc plated
• Size: 200mm
• Weight: 0.34kg
• Use: External

Typical Applications

• Securing wooden garden gates
• Fastening shed and outbuilding doors
• Locking fence panel gates
• Securing garage side access doors
• Double door installations with recessed frames
• Outdoor storage unit closures

How to Use

• Mark the Position: Hold the backplate against the door surface and mark the screw hole locations with a pencil.

• Drill Pilot Holes: Drill pilot holes at the marked positions to prevent splitting the timber.

• Fix the Backplate: Screw the bolt backplate firmly to the door using the supplied fittings.

• Locate the Keep: Slide the bolt to the closed position and mark where the keep should sit on the gate post or frame.

• Fit the Keep: Screw the keep to the frame, aligning it with the bolt throw.

• Test the Action: Slide the bolt back and forth to check for smooth, unobstructed operation before regular use.

Frequently Asked Questions (FAQs)

• What is a necked tower bolt?
  A necked tower bolt - also called a cranked bolt - has an angled or offset section that bridges the gap between a door face and a recessed frame. This allows the bolt to throw securely into the keep, even where the door and frame are not on the same plane.

• What is the difference between a necked tower bolt and a standard tower bolt?
  A standard tower bolt uses a straight sliding mechanism and works where the bolt and the keep sit flush on the same plane. A necked bolt has a cranked section that offsets the bolt head, making it the right choice for doors and gates where the frame is recessed or sits deeper than the door surface.

• Can a necked tower bolt be fitted horizontally?
  Yes. A necked tower bolt can be installed either horizontally or vertically, depending on the gate or door configuration. This gives more installation options compared to bolts that only work in one orientation.

• Is a zinc-plated tower bolt suitable for outdoor use?
  Yes. Zinc plating creates a protective layer that resists rust and corrosion, making it suited to outdoor applications on gates, shed doors, and fences. For coastal or heavily exposed environments, a stainless steel finish would offer greater long-term protection.

• Can a necked tower bolt be used on double doors?
  Yes. The cranked neck design makes necked tower bolts well-suited to double door setups, particularly where one door has a recessed frame. The offset allows the bolt to throw securely into the keep even when the two door faces don't sit on the same plane.

Summary

The Blue Spot Tools 200mm zinc-plated necked tower bolt gives a practical solution for securing recessed-frame gates, shed doors, and outdoor fencing. Carbon steel construction paired with a zinc-plated finish makes it suited to permanent outdoor installation. Supplied with all necessary fittings and backed by a 5-year guarantee.
