Fixman Masonry Anchor Through Bolt Fixing M12 180mm 10pk 631836

Fixman Masonry Anchor Through Bolt Fixing M12 x 180mm (Pack of 10) – 631836

Size: M12 - 12 x 100 x 180mm

MPN: 631836

Barcode: 5024763181429

Product Overview:

The Fixman M12 x 180mm Masonry Anchor Through Bolt Fixings are designed for maximum strength and extra-deep anchoring into solid masonry materials such as concrete, brick, and stone. With a substantial 180mm length, these bolts are ideal for demanding applications requiring deeper embedment and high load-bearing performance. Supplied in a value pack of 10, they are a go-to choice for professional contractors and industrial use where secure, long-lasting fixings are critical.

• Fixman zinc-plated steel bolts for use in concrete, masonry, metal and wood.
• Torque-controlled, heavy duty expansion anchor for rapid fixing of steel and timber assemblies, structural components, base plates and brackets.
• Load-assisted through fixing, eliminating the need for setting out.
• Yellow chromated for corrosion resistance

Quick and easy to use:

1. Simply drill through the work piece.
2. Insert the through bolt and tighten.

Size guide:

• M12 - 12 x 100 x 180mm
• M12 = Drill size
• 100 = maximum material thickness the bolt will fasten 100mm
• 180mm = length of fixing
• Minimum Hole Depth 80mm
• Drill Size Required 12mm

Key Features:

• Heavy-duty M12 through bolts with extended 180mm length

• Ideal for extra-deep anchoring into solid substrates

• Zinc-plated finish offers corrosion resistance

• High-performance fixings for structural and industrial use

• Quick and easy through-fix installation

• Supplied in a convenient pack of 10 fixings

Applications:

• Anchoring large steel base plates and heavy machinery

• Securing structural supports, brackets, and frames

• Fixing fencing posts, gates, and industrial equipment

• Suitable for concrete, stone, and solid brick installations

Specifications:

• Product Code: 631836

• Size: M12 x 180mm

• Quantity: 10 fixings per pack

• Material: Zinc-plated steel

• Installation Method: Drill 12mm hole, insert bolt through fixture, tighten to expand and lock

Frequently Asked Questions:

1. What type of surfaces can these fixings be used with?
   Designed for solid masonry such as concrete, solid brick, and stone.

2. What drill bit size is needed for installation?
   Use a 12mm masonry drill bit for precise fitting.

3. Are these bolts suitable for heavy-duty loads?
   Yes, the M12 diameter and 180mm length provide exceptional strength and holding power.

4. Are nuts and washers included?
   Yes, each fixing comes complete with matching nut and washer.

5. Can these be used outdoors?
   The zinc plating provides moderate corrosion resistance, suitable for indoor and some outdoor applications.

6. Can I use these in hollow walls or plasterboard?
   No, they must be installed in solid masonry for proper performance.

7. Are they reusable after removal?
   No, these fixings are designed for permanent installation and are not intended for reuse.

8. Are they appropriate for overhead applications?
   Yes, provided the substrate is solid and the load is within safe limits.

9. What tools are needed for installation?
   A spanner or socket wrench is recommended for tightening the nut and expanding the anchor.

10. Why choose 180mm bolts over shorter versions?
    The extended length offers deeper penetration and higher load capacity, ideal for thicker fixtures or substrates requiring superior anchoring.
