Blue Spot Tools Individual 11mm Shallow Hex Socket (1/2" Drive) 01723

Blue Spot Tools Individual 11mm Shallow Hex Socket (1/2" Drive)

MPN: 01723

Barcode: 5028734017236

Size: 11mm

Weight: 0.06kg

Overview:

The Blue Spot Tools 11mm Shallow Hex Socket is a 1/2" drive, chrome vanadium hand tool socket rated to 178Nm. CrV steel provides the hardness and wear resistance needed for repeated torque loading at this compact metric size.

A mirror-polished body and knurled midsection band give a corrosion-resistant finish and a grip surface for handling in oily conditions. The 38mm depth keeps the socket practical in tight access points, connecting directly to any standard 1/2" drive tool.

Key Features and Benefits

• CrV Construction: Provides hardness and wear resistance for repeated torque loading
• 178Nm Torque Rating: Covers hand tool applications for 11mm metric fasteners
• Six-Point Hex: Contacts the flat faces of the fastener head through the full rotation
• Mirror Polished Body: Corrosion-resistant finish that cleans quickly in working conditions
• Knurled Band: Grip surface when handling the socket in oily or greasy conditions
• 1/2" Drive: Connects to ratchets, torque wrenches, and breaker bars
• 38mm Depth: Stays practical in access points where overhead clearance is limited

Specs & Attributes

• Size: 11mm
• Drive: 1/2"
• Type: Hex (6-point)
• Material: Chrome Vanadium (CrV)
• Finish: Mirror polished with knurled grip band
• Max Torque: 178Nm
• Depth: 38mm
• Weight: 0.06kg

Typical Applications

• Small body and trim bracket fasteners
• Interior component mounting hardware
• Electrical connector and sensor bracket bolts
• Light engine bay bracket hardware
• General 1/2" drive hand tool works on 11mm metric fasteners

How to Use

• Confirm the Fastener Size: Check that the bolt head measures 11mm across the flat faces before fitting.

• Attach to the Drive Tool: Fit the socket onto a 1/2" drive ratchet, torque wrench, or breaker bar.

• Seat the Socket: Place the hex opening fully over the fastener with no play before applying force.

• Apply Torque: Drive the fastener in the correct direction - do not exceed 178Nm.

• Remove the Socket: Disengage the drive tool and grip the knurled band to pull the socket clear.

Frequently Asked Questions (FAQs)

• What is an 11mm socket used for?
  An 11mm socket covers a range of small automotive fasteners, including body trim brackets, interior component fixings, electrical connector brackets, and light engine bay hardware. It is a compact metric size suited to detail work on vehicles and general mechanical tasks.

• Can a socket be used with a flex-head ratchet?
  Yes. A flex-head ratchet has a pivoting head that allows the socket to work at a slight angle, helping when a fastener cannot be accessed in a straight line. The socket connects in the same way as on a standard ratchet. Working at a significant angle reduces effective torque transfer, so apply controlled, steady force.

• What is the benefit of stamped size markings over painted ones on a socket?
  Stamped or engraved markings are machined into the steel and cannot wear off with use. Painted markings sit on the surface and fade over time, particularly in workshop environments where solvents and abrasion are common. Permanent markings make identification quick and reliable throughout the working life of the socket.

• What is heat treatment, and why does it matter for CrV sockets?
  Heat treatment is the process of heating steel to a controlled temperature and then cooling it at a specific rate to achieve the target hardness and toughness. For chrome vanadium sockets, heat treatment after forming converts the forged alloy into a tool-grade socket capable of handling repeated torque loads without deforming or cracking.

• Can surface rust on a chrome socket affect its performance?
  Light surface oxidation on the outer body does not typically affect hand tool performance. If corrosion develops in the drive recess or hex opening, it can affect the fit between the socket and tool or fastener. Keep sockets dry and stored away from moisture to prevent this from occurring.

Summary

The Blue Spot Tools 11mm Shallow Hex Socket is a CrV 1/2" drive hand tool socket rated to 178Nm for small metric fastener applications. The 38mm depth keeps it usable in tight access points where overhead clearance is limited. This socket is backed by the Blue Spot Tools Lifetime Guarantee.
